Vacuum Filter  (VF2001)

Pdt. Code:VF2001

3L filter flask, 40-80u glass mesh filter, 20L Receiving, Suck type w/sealing cap and stand
Equipped with wide caliber concave shape glass mesh, enable quick filtering under negative pressure.
Receiving flask has PTFE discharge valve.
  • Pdt. Name/Model: Vacuum Filter(VF2001)
  • Pdt. Code: VF2001
  • Pdt. Features:

SPECIFICATIONS

0 Type Suck or Pour Type Vacuum Filter
0 Filter Cup (L) 3L
0 Receiving Flask (L) 20L
0 PTFE Vacuum Pipe OD12mm/ID10mm
0 Sand Mesh Glass Filter Plate 40-80μm(grade changeable at request)
0 Dimensions (cm) 45x45x150H
0 Applications Closed system, suitable for filtering poisonous,harmful, volatile or dangerous solution

CONFIGURATIONS

Symbol Instruction: / - None,  ● - Equipped,  ○ - Optional ( * - Only available when ordering of product, not for separate sale)

Note: Some specifications of relevant or customized models have some differences from that of standard model, for details, please consult with us.
